The Incoplas LED Hybrid is a durable multi-purpose and corrosion-resistant LED lighting solution that can be used in heavy industrial applications where hazardous location lighting is required. This fixture can replace 100W and 250W metal halide lamps. The Hybrid uses thermally conductive engineered polymers to extract heat away from the light source and its natural convection allows for maximum thermal performance while minimizing energy costs.

Applications
Gas Stations, Grain Elevators, Food Processing, Pet Food Applications, Distilleries, Chemical Plants, Refineries, Pulp and Paper Mills, Power Generation, Waste Water Treatment Plants, Ship Yards, Mines, Petroleum

Specifications

Hazardous Classifications:

Class 1: Flammable gases & liquids
Division 2: The hazardous atmosphere is only available infrequently (i.e. in case of spill).
Groups A, B, C, D: Includes acetylene, hydrogen and similar gases to it, plus common flammable substances such as butane, gasoline, natural gas and propane.
Class 2: Dust
Division 2: The hazardous atmosphere is only available infrequently (i.e. in case of spill).
Groups F, G: Group F contains dusts consisting of or containing carbon or its compounds (i.e. coal), and Group G dusts are non-conductive dusts (i.e. grain, wood or plastic).
Class 3: Fibers or Flyings
Contains easily ignitable fibers or flyings, but the concentration of these fibers or flyings are not suspending in the air in such quantities that would produce ignitable mixtures.

Additional Information

  • Temperature Rating: T3C (Class 1), T4 (Class 2 & 3)
  • Dimensions: 13″L x 10.25″W x 5.6″H
  • Weight: 7.5 lbs
  • Lens: Clear or Frosted Polycarbonate
  • 1/2″ Stainless Steel NPT Connector Hub
  • Operating Temperature: -30C (-22F) to 45C (113F)
  • Optional Laminated Glass Lens
Weight 11 lbs
Brand

Shat-R-Shield

Wattage

81 – 90 W

Lumens

10001 – 12000

Voltage

120 V, 130 V, 200 V, 208 V, 210 V, 220 V, 230 V, 240 V, 265 V, 277 V

CRI

61 – 70

Certifications

American Made, DLC Premium, NSF Listed, UL Listed

Warranty

5 Years
